TP-Link ES205G Omada 5-Port Gigabit

Popis produktu:

Omada 5portový gigabitový Easy Managed Switch.
5× 10/100/1000Mb/s RJ45 portů.
Snadné použití: Podpora plug-and-play pro okamžité připojení a jednoduchá konfigurace dalších funkcí.
Centralizovaná správa v cloudu přes web nebo aplikaci Omada.
Automatická prevence smyček, VLAN a IGMP Snooping.
Bezventilátorový design pro tichý provoz.
Odolné kovové šasi a možnost instalace na stůl nebo na zeď.

HARDWARE FEATURES
Interface:
• 5× 10/100/1000 Mbps RJ45 Ports
• AUTO Negotiation/AUTO MDI/MDIX
Installation:
• Desktop
• Wall Mount
Physical Security Lock
Fan Quantity - Fanless
Power Supply - External DC Power Adapter (Output: 5 VDC/ 0.6 A)
Dimensions ( W x D x H ) 100 × 98 × 25 mm

PERFORMANCE
Switching Capacity - 10 Gbps
Packet Forwarding Rate - 7.4 Mpps
MAC Address Table - 8 K
Packet Buffer Memory - 4 Mbits
Jumbo Frame - 15 KB

SOFTWARE FEATURES
Quality of Service:  Port-based/802.1p/DSCP QoS • 8 Priority Queues • Priority Schedule Mode - WRR (Weighted Round Robin) • Queue Weight Config • Bandwidth Control - Port-Based Rating Limit • Storm Control
- Multiple Control Modes (kbps/pps)
- Broadcast/Multicast/Unknown-Unicast Control?
L2 Features: Static Link Aggregation • Loop Prevention / Loopback Detection • Flow Control - 802.3x Flow Control • 802.1ab LLDP
• Mirroring
- Port Mirroring
- One-to-One
- Many-to-One
- Ingress/Egress/Both
• Port Statistics
- Port Mirror Status
- Traffic Statistics
L2 Multicast:
• IGMP Snooping
- IGMP v1/v2/v3 Snooping
- Fast Leave
VLAN:
• MTU VLAN
• Port-Based VLAN
• 802.1Q Tag VLAN
- Max 32 VLAN Groups
- 4K VID
Transmission Method - Store-And-Forward

MANAGEMENT
Omada App - Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.
Centralized Management:
• Omada Cloud-Based Controller
• Omada Hardware Controller
• Omada Software Controller
Cloud Access - Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.
Zero-Touch Provisioning - Requires the use of Omada Cloud-Based Controller
Management Features
• Web-based GUI
• DHCP Client
• Cable Diagnostics
• Automatic Device Discovery
• Batch Configuration
• Batch Firmware Upgrading
• Unified Configuration

OTHERS
Package Contents
• ES205G
• Power Adapter
• Installation Guide
• Rubber Feet
Environment
• Operating Temperature: 0C~40C
• Storage Temperature: -40C~70C
• Operating Humidity: 10%~90% non-condensing
• Storage Humidity: 5%~90% non-condensing
Certification  FCC, CE, RoHS
